Motors: Get The Max Out Of Your Dish

Satellite Motors can be very intimidating for people just starting with Free to Air but in fact it is very easy to install with the proper equipment and tools. The same principles apply with motorized dishes and stationary dishes. All mounting hardware must be in installed exactly at 90 degrees and pointed west to south west depending on the satellite. Below is a video from YouTube posted by a company from the United Kingdom called HISTA as well as some frequently asked questions.




Frequently Asked Questions


Do I need a separate power line to connect to the HH Motor?
No. The motor gets its power from the receiver using the same coaxial cable running from the receiver to the LNBF on the dish. You simply disconnect the cable from the LNBF. Connect it to the HH Motor. Then run a short coaxial cable between the motor and the LNBF. You are set.



How do I control the motor to move it East / West?

The motor is controlled by the receiver's remote control. All receivers compliant with the DiSEqC 1.2, 1.3, or USALS protocol have the capability to run an HH motor. Once you initially setup the motor on the satellite arc and store the locations of the satellites, you will be able to move between satellites by simply changing the channel.



Does the motor also adjust for variation in elevation on the dish for each satellite?

Yes it does.



Do I need to skew the LNBF on a motorized dish?

No you don't. Just set the skew at 0 and the motor will tilt the whole dish when it moves.



What is the benefit from motorizing my dish?

Well, by adding a motor to your system you will be able to receive satellite channels from several satellites instead from one only. That way you will gain many more channels economically without investing in many dishes and switches.

Which motor goes best with what dish?

We have found out that majourity of dishes on the market do not fit and require modifications to the satellite dish. The 18' dish is the most common dish that requires modification and might require you to grind or cut some pieces off the hardware. The best dish to use that is under 90 cm is the 22" Elliptical Satellite Dish with the one LNB positioned in the center of the bracket.

What Motor is the best to use?

The SG 2100 is the easiest to install and is compatible with most dishes without any modification. The SG 2100 has position buttons right on the motor so you can move the dish east to west without using your receiver. The Stab HH90 and Stabb HH120 are made in Italy and are rated to have the best quality parts. The Stab series uses metal gears while other motors use plastic gears. The disadvantage is Stab motors do not have position buttons on the motor and usually require modifications to dishes when installing.

My LNB is circular but I will like to watch a satellite that requires a linear lnb?

Only the Invacom LNB can offer the option to switch from circular to linear. This is a quad output LNB and has two circular and two linear outputs. To control the LNB any 4x1 or sw 21 switch will work. Most linear signals require dishes to be 33” or bigger.

How many televisions can I hook up?

There is no maximum number but do make sure your multi switch has enough outputs to go to as many receivers as you want. Please note that all receivers will have to view the same satellite at the same time.


Where can I find out what channels are available free to air?

There are many free to air channels available in North America on satellites such as Galaxy 10R, AMC4, IA5, AMC3, etc. There are channels from the USA and from around the world. Visit Lynsat for a complete listing of what is available. Anything with an F designation is FREE TO AIR.

Pocket Toner Coax Continuity Tester

The Coax Cable Continuity Tester is an easy to use tool for testing coax cable. With it you can check DC shorts, splitters and self-grounding devices in coax cable. An audible tone sounds when the line-carrying signal is detected. Don't spend hours trying to figure out which coax cable goes to which jack. Save time during wiring projects with this pocket-sized Pocket Toner continuity tester. After completing the pre-wiring stage of an installation, you could be faced with dozens of coax cables. While it is easy to group the different cables, you still have to figure out which cable goes to which jack or location. The Pocket Toner can help you solve this problem in minutes.Simply plug the sender into a wall jack in a room. Back at the location where all the cables come together, connect one cable at a time to the speaker until a tone is heard, and you've found your cable.

Specifications

Specifically designed for RF cable applications
Easy-to-store toner stores in base for easy access
Right angled, male push-on connector for fast use female toner connector is also a quick-connect design
Dual female F-connector (included)
12 Volt 23A battery (included)
Measures 4-1/8" x 1" x 3/8"

RG6 Cable 101

RG6 is the recommended coaxial cable for distributing signals from cable TV, satellite dish or from a roof-top antenna. The RG6 cable construction provides better sheilding than the older RG59 coax cable. RG6 cables that we carry is available in 100 and 1000 foot lengths.

RG6 Application

• RG6 Cable For Cable TV 1 GHz (1000 MHz)
• High End Low Loss RG6 Cable For DBS/Satellite/HDTV 3.0 GHz (3000 MHz)
• Broadcast Quality Low Loss RG6 Cable For HDTV,Home Theater and Broadcast Studios 4.5 GHz (4500 MHz)


Coaxial cable is called "coaxial" because it includes one physical channel that carries the signal surrounded by another concentric physical channel, both running along the same axis. The two channels are seperated by a layer of insulation and there is additional insulation around the outer concentric physical layer

We Support Canada

Sky High Electronics Proudly Supports our Men and Women

Participating in This Year’s Summer Olympics in Beijing

GO CANADA GO

How To: Crimping & Stripping RG6 Cable Using Snap N Seal Connectors

In this video we will be showing you how to properly strip and crimp your own RG6 cable using the tools from Sky High Electronics. We always reccomend using water proof connectors to guarante a proper seal and to prevent any kind of shorts. For this reason we only recommend using Thomas & Betts Snap N Seal connectors.

Quick Connect

Constantly unscrewing your cables from your satellite receiver or television? Need a faster way to switch LNBs while trying to line up a multi LNB satellite dish? The Quick Connect connector is your solution. Made with gold & silver plating for high performance this is one connector you don’t want to be without. Constantly unscrewing cables from your receiver will eventually damage your tuner which can cost you a lot of money and time to replace. Trying to aim a multi satellite dish screwing and unscrewing your connections can be a nightmare, but with the open boot design you can simply push and pull off your connector without screwing anything. Sky High Electronics offers the Quick Connect for sale individually or in packages of 100. Get your Quick Connect today!

New Weekly Blog Sale

Sky High Electronics is happy to announce our new weekly Blog sale promotion. Every week we will have new products on sale for that week only. This is only a Blog special and customers must call in and mention the Blog to get the sale price. Walk in customers must bring in a printed flyer to the store. These are only one week sales so you must jump on it fast. COD is not available for these promotions. Credit Card and Pay Pal only accepted.

Motor Tips For This Spring

If you have a motorized satellite system you should keep the moving parts and pivot points lubricated. This cuts down on wear both on the moving parts and on the motor that drives your dish. Keeping your dish lubricated will keep it more accurate for a longer period of time.

New Version 2 Viewsat Ultra 2000 In Stalk

Viewtech Inc. has recently imported a NEW VERSION 2 ULTRA and is now available to purchase at Sky High Electronics. This version is currently for sale in Canada. Viewsat is now using a higher quality Samsung tuner and have made other improvements to the internal hardware. Distributors, Dealers, and Consumers please take note to the external changes so that these new Ultras are not confused with clones.

Please take note of the NEW Version 2 ULTRA seen below. You will notice that the power switch is positioned horizontally. There are also other noticeable changes to the rear panel. The side panel has changed as well.

The VIEWSAT ULTRA is best selling Free To Air Receiver. Viewsat added a faster processor (200 MHz), double the memory of the Xtreme (32 Mb SD RAM), and a USB communications port for easy data updates. Now you can use your USB flash drive to update your receiver. The new universal remote that comes with this unit is awesome. If that's not enough, wait until you see the new colorful Graphic User Interface. This is by far the best FTA STB the market has ever seen.

Next Gneration Anywhere Remote

The Next Generation Anywhere Remote is unlike anything else on the market. It allows you to control all your equipment from anywhere in your home, up to 100 feet using your current remote. Unlike other bulky remote extenders that attach to the front of a remote, or IR to RF base stations, this one fits in the battery compartment. Small and unobtrusive, you will never know it's there. It doesn't matter where you are in your home; in the living room with the equipment, in the master bedroom, or outside, you have total control. Installation could not be easier, simply remove one of the batteries from your remote and replace it with the RF transmitter battery, hook up the receiver base, attach the IR emitter and you are done. You now have a remote that does both IR and RF for a fraction of the cost of other RF systems. With the Next Generation Remote Extender you will never miss a movie or sporting event from anywhere in your house. Simply wire two TV’s anywhere in the house using RG6 cable connecting one television from input TV IN and the other to output TV Out. Bring your remote with you to the other room without the receiver and now your able to change channels from anywhere in the house. Now you can watch the end of a movie in the comforts of your bedroom and be able to save money at the same time. There is no need to buy additional satellite receivers if you only use one TV at a time. Buy your Next Generation Anywhere Remote only at Sky High Eectronics

Note
Two RF kits, with different frequencies, are required for two separate remote controls to be used at two different component locations without interference. If you have any questions are Sky High sales team is waiting by to answer them.

New Authorized EMP Distributor PEI/NS/NF/NB Canada

New Launch of Viewsat Warranty Website

Sky High Electronics is proud to launch in Canada this fall http://www.viewsatwarranty.com/. If you have a warranty issue or need your Viewsat receiver repaired you can simply register your receiver online and track the status anytime 24 hours 7 days of the week. All Canadaian dealers are welcome to use this website. Another innovative idea thanks to the Sky High Electronics team.

EMP Centauri PROFI LINE 4x1 DiSEqC Switch

Pro Series Cable Stripper

The name says it all. The Pro Series Cable Stripper works like magic with all types of RG-6 satellite cable. The new design makes stripping cable a breeze with thumb adjustable blade settings and spring loaded to ensure your blades cut through to the proper depth. Pro Series Cable Stripper on Sale $19.99

Obstructions in Your Way of Finding a Perfect Signal? Sky High Electronics Has the Solution

Cant clear the tree in front of you? Is your neighbors house blocking your line of sight? Do you just need a little extra clearance or height to get an optimal signal? We have what you have been looking for it’s called the J-Style Satellite Mount. The monster of all satellite poles is 36” long and twice the size of a standard satellite mount. Designed with high quality galvanized steel this mounting pole will help you find signal strengths that you have never imagined. On sale for $29.99 only at Sky High Electronics

Thomas&Betts Snap-N-Seal Connectors Have A Different Look

This difference is a result of the new Nickel-Tin (NiTin) plating process. The NiTin plated products meet or exceed specified physical and electrical criteria and provide the same outstanding performance that you expect from Thomas&Betts products.

As an added bonus, adopting this NiTin plating process helps reduce the impact on the local environment and comply with global environmental directives for broadband connector products.

How To Order From www.skyhighelectronics.com

1. 2.

3.4.5.

5.6.

7.8.

9.

New Launch Of Wholesale Section

Link

IN STOCK ACER DUAL LNB

Highest signal strength than any other LNB on the market

Fits Rectangular Tube LNBF Arms.

Input Frequency 12.2 to 12.7 GHz

Output Frequency 950 to 1450 MHz

Noise Figure 1.1 dB, Max

Gain 50 to 62 dB

Sale $19.99

Low Shipping Rates for All of Canada

Free Cash on Delivery Service. We pay the COD Charge for You. No Credit Cards Needed

Full Time Shipping Staff to Insure Your Package Arrives On Time

All Orders Are Insured and Backed By Sky High Electronics

Custom Boxes Specifically Designed For All Receivers and Accessories

We Ship To All Rural Areas in Canada and Use Only Canada Post

New Products For June

The X-5 is the only bracket on the market that holds up to 5 of the same model LNBs and can be used on a 22” Elliptical Dish. The sleek and rugged design helps with easy installation and fits all styles of LNBs

Acutrac 22 Dual Pro Satellite Meter is the newest and affordable digital satellite finder on the market. Voted the best Pocket Satellite Finder by NASC

New switches this summer from the EMP Centauri line available at Sky High Electronics. We have the biggest selection of EMP Centauri Switches in Canada. We will match or beat any advertised price on the internet in Canada

Chieta 4x1 Diseqc switch supports all protocols like 1.0, 1.2, 1.3, 1.6, and 2.0. Other switches only supports protocol 2.0.

This RCA KIT contains the necessary hardware and an instructional video to help you understand the installation process for a satellite system dish. Make the set-up and hook-up of your unit as easy as possible, get this kit today! Works with all FTA digital satellite systems $14.99

From the secret performance labs at Western Digital comes the revolutionary 250Gb HD $89.99

BIRDOG Goes USB

Sky High Electronics is proud to introduce to its product line the new Birdog USB 3.0 .
The USB BIRDOG satellite meter is hands down the best satellite locator in the satellite industry today. This meter was specifically designed for Satellite Installers and has the ability to ID over 100+ different satellites .

New Improved Features


USB Connectivity $549.99
Easy-to-Read Display with Digital Enhanced Graphics
Twice the Satellite Memory Positions
One-Touch Buttons-Easy to Use
More Baterry Life-Over 2 Hours on Full Charge
Spanish Language Display Options
Recalls Last Satellite Position upon Power-up

For wholesale and dealer pricing please contact us at sales@skyhighelectronics.com or to talk to a sales rep please call 1-866-372-5104

Maximize your set up with a 22KHz switch

With so many different switches on the market today it can get confusing for a lot of people entering this hobby. One switch that always gets left behind is the 22 KHz switch. This switch has many uses and can be integrated into complex set ups. The 22 KHz switch can replace a Diseqc switch (Diagram 1) or can be used to multiply the existing ports on your Diseqc switch (Diagram 2).

This diagram shows a 22 KHz switch taking the place of a Diseqc Switch. 2 Satellites to 1 Receiver. Only works with Standard LNB not Universal.

This diagram shows a 4x1 Diseqc switch being converted to a 5 x1 Diseqc switch using a 22 KHz switch.

New EMP 22 KHz Switch

On Sale $19.99

The Satellte Diplexer: A Semless Solution

Q :I Just purchased an FTA receiver and I will like to stay with my local cable network/antenna service?

A: The Satellite Diplexer: A Seamless Solution! Satellite programming may not offer local network or independent TV channels in your particular area. Fact of the matter, there is a large portion of rural America that is not covered. The solution is actually quite simple: capture those signals with either an off-air (uhf/vhf) antenna or cable TV feed and add them to your channel line-up.

You can run two lines: one line from your satellite dish and the other line from your local channel source OR you can use two signal diplexers and run both signals down ONE coaxial cable line SIMULTANEOUSLY (Diagram 1). One diplexer is used outside to combine the two separate signals (one signal from the satellite dish and another signal from either an off-air TV antenna or cable TV feed). A second diplexer is used inside to separate the combined signals before they enter your satellite receiver (Diagram 3). Satellite diplexers eliminate the need for extra wiring thereby reducing the cost of labor and installation materials necessary to run two coaxial lines.



Combining LNB and Antenna/Cable through 1 Line Diagram 1



Combining LNB with Antenna/Cable Through a Multiswitch





Connecting Diplexer To Satellit Receiver Diagram 2

Portable Satellite Systems

Satellite dish tripods are lightweight and easy to transport. Tripods are excellent for helping your satellite dish clear railings, fences, trees and other obstacles. RV'ers love them, and apartment dwellers keep their landlords happy. These tripods are heavy duty and made of high quality stainless steel.

Take your satellite system on the road with you. Tripods are perfect for outdoor events and activities. It has 3 holes in each foot for secure mounting. Works great with the Eliptical Dish, 18" Dish and 90 cm Dish.

If you need something smaller and more compact you might want to consider a Mini Satellite Dish. These dishes are perfect for truck drivers or just those times you need a temporary satellite signal. It comes with a suction cup that mounts to any surface such as glass or metal and does not require any mounting screws.

The mini satellite dish is perfect to mount on top of your car or even on glass windows. Receive the same signal strength as an 18" dish. Comes with a plastic carrying case that fits any standard FTA size receiver like a Viewsat or Sonicview.
